Box: 18 mm multi-layer board with internal reinforcement. Surface treatment: five layers of water-soluble paint (color can be customized according to customer requirements). Protective grating: 1.5mm sound permeable steel plate. Frequency divider: built in passive frequency divider network, modular design.
Box: 18mm multilayer board with internal reinforcement
Surface treatment: five layers of water-soluble paint covering (color can be customized according to customer requirements)
Protective grating: 1.5mm sound permeable steel plate
Frequency divider: built in passive frequency divider network, modular design
Lifting point: 5-point pre installed hanger, 1 standard 35 mm support base
Input connection point: 2 nextrik speakon nl4mp & nbsp; speaker connectors
Unit composition: Bass unit：1*12" Voice-coil :76mm Treble unit：1*1.5"Voice-coil:75mm | Frequency response(+/-3dB):60--20 000Hz |
Coverage angle（-6dB):60 degrees (horizontal) * 60 degrees (vertical) | Sensitivity：101dB@1W.M |
Maximum sound pressure level：132dB | Standard impedance: 8 ohm |
Input power: 450 W (rated) 1800 w (peak) | Net size（H * W *D）：540mm*410mm*410mm |
Net weight：（KG）：20 |
